TP-Link TL-SG3428MP Gigabit L2 Managed Switch with 24-Port PoE+
$823.00
TP-Link TL-SG3428MP, Gigabit L2 Managed Switch with 24x PoE+ Ports, 4x SFP+ Slots, and Omada SDN integration.
Out of stock
Description
Weight & dimensions
| Depth | 180 mm |
|---|---|
| Height | 44 mm |
| Width | 440 mm |
Power
| AC input frequency | 50/60 Hz |
|---|---|
| Power supply included | Y |
| Power consumption max | 463.8 W |
| AC input voltage | 100 – 240 V |
Ports & interfaces
| Basic switching RJ-45 Ethernet ports quantity | 24 |
|---|---|
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| SFP module slots quantity | 4 |
| Console port | RJ-45 |
Network
| Quality of Service QoS support | Y |
|---|---|
| Networking standards | IEEE 802.3af,IEEE 802.3at |
| Jumbo frames support | Y |
| VLAN support | Y |
| Link aggregation | Y |
| Broadcast storm control | Y |
| Rate limiting | Y |
| Spanning tree protocol | Y |
| 10G support | N |
| Head-of-line HOL blocking | Y |
| Port mirroring | Y |
| IP routing | Y |
| Active link detection | Y |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
Security
| Static port security | Y |
|---|---|
| SSHSSL support | Y |
| Loop protection | Y |
| BPDU filteringprotection | Y |
| DHCP features | DHCP client,DHCP server |
| Authentication | MAC-based authentication, Port-based authentication |
| Access Control List ACL | Y |
| IGMP snooping | Y |
| MAC address filtering | Y |
Data transmission
| Switching capacity | 56 Gbit/s |
|---|---|
| Forwarding rate | 41.66 Mpps |
| MAC address table | 8000 entries |
Management features
| Switch type | Managed |
|---|---|
| Switch layer | L2/L2+ |
| Web-based management | Y |
| Cloud-managed | Y |
| ARP inspection | Y |
| Configuring Location Settings CLI | Y |
| System event log | Y |
Other features
| Flow control support | Y |
|---|
Power over Ethernet PoE
| Power over Ethernet PoE | Y |
|---|---|
| Power over Ethernet PoE ports quantity | 24 |
| Power over Ethernet PoE power per port | 30 W |
Operational conditions
| Operating temperature T-T | 0 – 45 °C |
|---|---|
| Storage temperature T-T | -40 – 70 °C |
| Operating relative humidity H-H | 10 – 90% |
| Storage relative humidity H-H | 5 – 90% |
Design
| Product colour | Black |
|---|---|
| Rack mounting | Y |
| Number of fans | 2 fan(s) |
Packaging content
| Quick start guide | Y |
|---|
Certificates
| Certification | CE, FCC, RoHS |
|---|
Multicast features
| Multicast support | Y |
|---|
Packaging data
| User guide | Y |
|---|
Features
| LED indicators | Y |
|---|
Additional information
| Interface | 24 x 10/100/1000 mbps rj45 ports (ports 1–24 support 802.3af/at poe+), 4 x 10 gbps sfp+ slots |
|---|---|
