Ubiquiti UAP-AC-M-PRO, UniFi Mesh Pro Outdoor Access Point, 802.11AC 3×3 MIMO, 2.4GHz: 450Mbps, 5GHz: 1300Mbps, 1 Year Warranty
Stock Availability (LIVE)
- • Brisbane Warehouse ✓ In Stock (11)
- • Sydney Warehouse ✕ Out of Stock (0)
- • VIC Warehouse ✕ Out of Stock (0)
- • WA Warehouse ✕ Out of Stock (0)
- • SA Warehouse ✕ Out of Stock (0)
Delays may be experienced from Sydney Warehouse as warehouse is currently changing location.
Call for corporate/edu qty purchases
Same Day Shipping
Order within –:– for same day dispatch!
Shipping cutoff time: –:–
Ubiquity UAP-AC-M-PRO, UniFi AP AC Mesh PRO 802.11ac Dual Radio Indoor/Outdoor access point - 1750Mbps, 1 Year
Overview :-
UniFi 802.11AC Outdoor Access Point Mesh Pro, 1750Mbps
- Weather-Resistant Form Factor The enclosure of the UniFi AC Mesh Pro AP is designed to withstand the elements, making it ideal for outdoor deployment.
- LED Unique provisioning LED provides administrator location tracking and alerts for each device.
- Powerful Coverage Built-in dual-band omnidirectional antennas deliver expanded range coverage outdoors.
- Mounting Flexibility The UniFi AC Mesh Pro AP can be mounted on a wall or pole. (All accessories are included.) Dual Gigabit Ethernet Ports The primary port is for data and PoE; the secondary port is for bridging.
- Multiple Power Options You can power the UniFi AC Mesh Pro AP with an 802.3af compatible switch, UniFi PoE Switch, or the included Gigabit PoE adapter. We recommend powering your UniFi devices with a UniFi PoE Switch (sold separately).
Specifications:
0: Height,343.2 mm | 1: Weight,633 g | 2: Width,181.2 mm | 3: Depth,60.2 mm
0: Quality of Service QoS support,Y | 1: Networking standards,IEEE 802.11a,IEEE 802.11ac,IEEE 802.11b,IEEE 802.11g,IEEE 802.11k,IEEE 802.11n,IEEE 802.11r,IEEE 802.11v,IEEE 802.1Q,IEEE 802.3,IEEE 802.3ab,IEEE 802.3af,IEEE 802.3u | 2: VLAN support,Y | 3: Ethernet LAN data rates,10,100,1000 Mbit/s | 4: Cabling technology,10/100/1000Base-T(X) | 5: MIMO,Y
0: Power consumption max,9 W
0: Antenna direction type,Omni-directional | 1: Antenna features,Integrated antenna | 2: Antennas quantity,3 | 3: Antenna gain level max,8 dBi | 4: Antenna type,Internal
0: Power over Ethernet PoE,Y
0: Ethernet LAN RJ-45 ports,2
0: Operating relative humidity H-H,5 - 95% | 1: Operating temperature T-T,-40 - 70 °C
0: Maximum data transfer rate,1750 Mbit/s | 1: 2.4 GHz,Y | 2: 5 GHz,Y | 3: MIMO type,Multi User MIMO | 4: Maximum data transfer rate 2.4 GHz,450 Mbit/s | 5: Wi-Fi MultimediaWMMWME,Y | 6: Maximum data transfer rate 5 GHz,1300 Mbit/s | 7: Security algorithms,AES,TKIP,WEP,WPA,WPA-Enterprise,WPA-PSK,WPA2 | 8: Output voltage,44 - 57 V
0: Product colour,White | 1: Placement,Ceiling, Pole, Wall
0: Reset button,Y
0: Number of users,250 user(s)
0: Mounting kit,Y
0: Certification,CE, FCC, IC
0: PoE adapter included,Y
No specifications Table available.
