Zalman P30 BLACK V2, Mini Tower, Tempered Glass, Drive Bays: 2 x Combo Bay (3.5“ or 2.5”), Expansion Slot: 5, Motherboard Support mATX / Mini-ITX, 1 Year Warranty

Modern and Clean Asethetic

Designed for maximum desk

appeal showcasing components

Panoramic View with

Seamless Tempered Glasses

Two frameless front and side tempered glasses

showing unique PC build

Tool-Free Tempered Glasses

The front and side panels can be easily and

completely removed for convenient access to

PC components

■ Tool-free ball head structured front and side

tempered glass enhances user's convenince

■ Easy panel management with groove fixing structure

at the bottom of the tempered glass

Easy accessible I/O ports

■ USB Type-C

■ Microphone / Headphone

■ USB 3.0

■ Power

Maximized Ventilation and Airflow

■ Pre-installed ZM-AF120 3 x 120mm

addressable RGB fans provide full customization

via a 3-pin header connection.

Rear (ZM-AF120)/Side (ZM-AF120R)

- Dimensions : 120 x 120 x 26(T)mm
- Rated Voltage : 12V DC (LED : 5V)
- Fan Speed : 600~1,500RPM±10%
- ZM-AF120 Max Air Flow : 53.72CFM±10%
- ZM-AF120R Max Air Flow : 46.6CFM±10%
- Bearing Type : Hydro Bearing
- Connector : 4-Pin (12V) / LED 3-Pin (5V)


■ Two 120mm reverse fans on the side effectively

pull fresh air from the outside into chassis,

while the rear fan blows hot air out to maximize

air flow and cooling performance.

Radiator Configuration

■ Top : 120mm / 140mm / 240mm / 280mm / 360mm

■ Rear : 120mm / 140mm

Fan Support

■ Top : 3 x 120 mm / 2 x 140mm

■ Rear : 1 x 120mm / 1 x 140mm

■ Bottom : 3 x 120mm / 2 x 140mm

■ Side : 2 x 120mm

Motherboard Support

■ Mini- ITX

■ mATX

Dedicated GPU Bracket included

Prevents GPU card bending

Supports various GPU cards according to

height adjustment

Intuitive Cable Management Layout

Convenient cable management layout makes it easier

than ever to organize messy cables for a clean look

&

Rubber grommets included for

Clean Cable Management

Excellent Expandability

and Convenience

The P30 has plenty of space to offer upgraded

performance features, compatibility

with high-end PC components,

and even custom liquid cooling

※ This image is intended to help understnad the

product

Rear Layout

■ Side Panel Handle

■ Rear Hand Screw

■ Rear 120mm ARGB fan (Pre-installed)

■ PCI Slots x 5

■ Rear Air vent

■ PSU Slot
