Micron 7500 Pro 15TB Gen4 NVMe Enterprise SSD U.3 7000/5900 MB/s R/W 1100K/250K IOPS 28032TBW 1DWPD 2M hrs MTBF Server Data Centre 5yrs

Micron 7500 Pro 15TB Gen4 NVMe Enterprise SSD U.3 7000/5900 MB/s R/W 1100K/250K IOPS 28032TBW 1DWPD 2M hrs MTBF Server Data Centre 5yrs

Features
• Micron® 3D TLC NAND Flash
• PCI Express Gen4
- U.3 single port (x4) backwards compatible with
U.2
• NVM Express:
- NVMe 2.0b Base Specification
- NVMe-MI 1.2b Specification
- Number of name spaces supported: 128
- Weighted round robin with urgent arbitration
supported
• OCP 2.0 Datacenter NVMe SSD Specification
• TCG Storage Security Subsystem Class: Opal Rev
2.01
• Capacity (unformatted)
- 7500 PRO U.3: 960GB, 1920GB, 3840GB, 7680GB,
15,360GB
- 7500 MAX U.3: 800GB, 1600GB, 3200GB, 6400GB,
12,800GB
• Endurance: Total bytes written (TBW)
- 7500 PRO: Up to 28,032TB at 1 DWPD
- 7500 MAX: Up to 70,080TB at 3 DWPD
• Enterprise sector size support = 512, 4096-byte
sector size (configurable)
• Security
- Digitally signed firmware
• Surprise insertion/surprise removal (SISR) and
hot-plug capable
• Self-monitoring, analysis, and reporting technology
(SMART)
• Field-upgradeable firmware with support for
activate without reset
• Performance1
- Sequential 128KB READ: Up to 7000 MB/s
- Sequential 128KB WRITE: Up to 5900 MB/s
- Random 4KB READ: Up to 1,100,000 IOPS
- Random 4KB WRITE: Up to 410,000 IOPS
• Latency2, 3
- READ (TYP): 80µs
- WRITE (TYP): 15µs
• Reliability
- MTTF: 2.0M hours @ 0–55°C and 2.5M hours @ 0–
50°C4
- Static and dynamic wear leveling
- Uncorrectable bit error rate (UBER): <1 sector per 1018 bits read - OCP 2.0-compliant end-to-end data protection - Enterprise power-loss protection • Operating temperature5 - Commercial (0°C to +70°C) • Form factor - U.3: 100.45 x 70.10 x 15.00mm • Electrical specification - U.3 power supply: 12V ±10% - U.3 AUX supply: 3.3V ±10% Notes: 1. Steady state as defined by SNIA Solid State Storage Performance Test Specification Enterprise v1.1. 2. 4KB, queue depth 1 transfers used for READ/ WRITE latency values. 3. TYP: Median, 50th percentile 4. Product achieves MTTF based on population statistics not relevant to individual units. 5. Temperature measured by SMART
